Note: open side of the cassette inlet is facing downward. Hang the pump on a worker’s belt, and clip the cassette holder in worker’s breathing zone. Turn the pump on using the on/off switch on the front panel. Feed the connector through the support plate of the holder and insert it into the OUTLET side of the cassette (image on the right). Your cassette assembly is ready.Ĭonnect free end of tubing to the pump. Take the cassette holder (left image) and place the cassette onto cassette holder with “open face” – open side of the cassette facing down. The assembled sampling train was mounted on the person operating the Metabo 12-125 HD Grinder assemblage with the filter cassette and cyclone located in the operator’s breathing zone. Take a cassette holder (upper right image) and locate round support plate. A Galson 37mm, 5µ, pre-weighted PVC membrane filter cassette, and Aluminum Cyclone. The inner part of the cassette is completely exposed. Use a coin or a screwdriver to gently pry off the inlet side of the cassette.
OSHA 42/47 methods require “open face” sampling where the inlet part of the cassette is completely removed. Dust is collected by the filter inside the sampling cassette, and clean air is removed from the cassette via the outlet port. Words “inlet” and “outlet” describe airflow direction through the sampling cassette, where air enters the cassette through the inlet port. The bottom part of the cassette (outlet) has a “wagon wheel” pattern. The picture on the left (above) shows inlet side of the cassette. Start preparation by removing red and blue stoppers from the inlet and outlet side of the cassette. For this project we will send you a portable air sampling pump calibrated at 1 L/min, tubing with attached cassette holder, and 37 mm cassettes designed to collect and preserve most common diisocyanates: HDI, TDI, IPDI and MDI.
#Galson breathing zone how to#
The kit is designed in strict compliance with Industrial Hygiene practice and will deliver the highest quality results. In this article we explain how to assemble sampling train to collect volatile diisocyanates using OSHA 42 and 47 methods. LCS Laboratory laboratory offers ready to use sampling kits for monitoring of of Isocyanates.
